| SUPERVISION |
|
The Supervision handheld game system, also known as the Travell-Mate, was a low-cost alternative to Nintendo's
world-famous Game Boy. Firms from across the world — Watara, QuickShot,
Hartung, Vini Spil, Electrolab, Magnum and others — brought licensed
variants of the Supervision to the market.
Most versions of the Supervision were bundled with a copy of the game
Crystball, to get players started gaming: literally right off the bat!
|
Many fun & exciting games to choose from!!
|
| |
M O D E L S |
There are three different models of the Supervision:
| The 9205 sports a bendable screen with kickstand. It seems to be the most common model.
The TV-Link's cradle was specifically designed to hold this variant of the machine.
The GB-2000 more closely resembles Nintendo's Game Boy. It does not feature a bendable screen or kickstand.
The 9600, more commonly referred to as Magnum after its brand name, is the slimmest, most compact model.
It lacks the two player link port, and it does not feature a bendable screen nor a kickstand.
It is incompatible with the TV-Link as well. However it is the only model of the
Supervision that can play Journey to the West.
Although certain firms assigned different model numbers to their machines
than those listed here, the actual product designs are the same.
|
|
| |
T E C H N I C A L S P E C I F I C A T I O N S |
|
CPU : 8-bit 65C02 processor, running at 4 MHz
Screen : 61 mm x 61 mm (2.37 inches x 2.37 inches), 160 x 160 pixels, 4 greys LCD
| Sound |
: |
2 Tonal and 1 Noise Channel plus additional audio DMA stereo output channel.
Built-in speaker and headphone jack with stereo earphones included. |
Power : 4 x AA batteries or 6V AC/DC adapter
Communication port : Two Player Link using DE-9 connector
| Other |
: |
Cartridge port
Tiltable Screen in some models (2 positions)
Game cartridges ranging in size from 32 kB to 512 kB |
| Optional |
: |
AC adapter
Car adapter
Carrying case with game pocket
TV-Link, to play games on the television screen |
No games released during the Supervision's original commercial lifespan made use
of the two player link port. |
|
| |
I N S T R U C T I O N S |
|
SECTION 1 |
 |
SUPERVISION Features
| 1. |
Power Switch (POWER) |
| 2. |
External Power Supply Jack |
| 3. |
Contrast Adjustment (CONTRAST) |
| 4. |
Direction Buttons |
| 5. |
Battery Cover (back) |
| 6. |
Headphones Jack (PHONES) |
| 7. |
Speaker |
| 8. |
A" & "B" Buttons - | Please refer the game
cartridges instruction. |
| 9. |
Select Buttons |
| 10. |
Start Buttons |
| 11. |
Volume Dial (VOLUME) |
| 12. |
Two Player Link (comm. port) |
|
| | | |
| SECTION 2
How to install the batteries?
| | • |
Remove the cover on the back of the SuperVision and insert the four "AA" batteries. |
| • |
Make sure that the batteries, plus (+) and minus (-) ends are facing the right directions. |
| • |
Do not use the rechargeable batteries. |
| • |
Do not use mercury oxide batteries. |
| • |
For best results, use alkaline batteries. |
| Important Notice: |
| • |
When changing a game cartridge, make sure the power is turned "OFF". |
| • |
When inserting a game cartridge into the SuperVision slot, please make sure the side with the LABEL faces outward. |
| • |
To get the best connection, make sure to press on the four rounded buttons of the direction control. |
|  |
| SECTION 3
| FAULT |
SUGGESTED ACTION |
| The display is black |
• Adjust the contrast |
| The LED is dim |
• Replace the batteries |
| | No sound can be heard during the game |
|
| • | Check that the game cartridge is inserted properly | | • | Adjust the sound volume |
|
| | There is nothing on the display when the power is turned on |
|
| • | Turn OFF the power, wait a moment and turn it ON again |
| • | Adjust the contrast |
| • | Check that the game cartridge is inserted properly |
|
|
| |
9205
GB-2000
9600
